Model: MH3250X60T
Description MH3250X60T hydraulic cold press machine features 1250×3000mm extended working platen, maximum pressing force 60 ton, targeted for extra-long wooden panels and door blanks. Three oil cylinders guarantee homogeneous pressure across full platen area. Users can choose 1000/1300/1500mm platen opening for various workpiece thickness. Working pressure stays stable at 20MPa with 4kW hydraulic motor. Rigid machine body resists bending deformation under long-time pressure. Net weight 2000kg, one unit fits 20GP container and two for 40GP. This cold press is widely used in wooden-door factories, cabinet workshops and panel furniture plants for veneer cold pressing, board compound and frame assembly pressing. It helps operators obtain smooth bonding surface, reduce reject rate and boost overall processing efficiency.
Main Features
- Extended 3000mm long platen for over-length panels
- 60-ton pressing power for door and furniture panel bonding
- Three-cylinder structure for uniform full-surface pressure
- Flexible adjustable platen opening for diverse workpieces
- Solid steel construction for stable long-term operation
- Moderate power consumption, good cost-performance ratio
- Easy to operate and convenient for overseas installation
| Parameter | Specification |
| Model | MH3250X60T |
| Working platen size | 1250×3000mm |
| Max total thrust | 60T |
| Hydraulic system pressure | 20MPa (≈200kg/cm²) |
| Max platen opening | 1000 / 1300 / 1500mm |
| Number of oil cylinders | 3pcs |
| Oil cylinder diameter | Φ125mm |
| Hydraulic motor power | 4kW |
| Overall size | 3200×1250×2200mm |
| Net weight | 2000kg |
| 20’GP loading | 1 set |
| 40’GP loading | 2 sets |
